NEO2 Blend
The NEO2 Blend series represents the ideal blender model for the NICU application. It comes with a 0-15 lpm flow meter close mounted to the left hand side (this makes an perfect spot to attach a resuscitation bag). The right side comes installed with either a 0-1, 0-3.5, or 1-15 lpm flowmeter (depending on the model you choose), which allows for use with a nasal cannula, CPAP, etc. The right side flow meter is installed on an integrated bleed control switch: when the right side is not needed, the bleed flow (3 lpm) can be disabled by pushing and rotating the flow meter forward when needed, simply return it to the upright position and use as desired.
Please use the form at the bottom of the page to enquire about wholesale or bulk pricing.
Description
The NEO2 Blend model features a 0-15 lpm flow meter very close mounted to the left side of the blender. This keeps the footprint as small as possible and minimizes the amount of wall space required. The Right side flow meter can be configured with three different options (depending on the needs and practice of the unit), but has a unique feature in that the bleed flow (3 lpm) can be disabled when the right side flowmeter is not needed, by simply pushing the flow meter in towards the body of the blender and rotating forward. To use the right side, simply rotate the flow meter to the upright position and the flow meter will automatically lock into place.
| Height | 6.64″ (16.9 cm) | |
|---|---|---|
| Width | 7.98″ (20.3 cm) | |
| Depth | 4.56″ (11.6 cm) w/flow meter on – 6.69″ (17 cm) w/flow meter off | |
| Weight | 3.17 lbs. (1.44 kg) | |
Ordering Information
2003FF1 NEO2 Blend with 15 lpm and 1.0 lpm flowmeters (green oxygen labeling)2003FF NEO2 Blend with 15 lpm and 3.5 lpm flowmeters (green oxygen labeling)
2003FF15 NEO2 Blend with 15 lpm and 15 lpm flowmeters (green oxygen labeling)
2003FFA NEO2 Blend with 15 lpm and 3.5 lpm flowmeters (green oxygen labeling) and bottom output
2003FFEU NEO2 Blend with 15 lpm and 3.5 lpm flowmeters (white oxygen labeling)
2003FFE5 NEO2 Blend with 15 lpm and 15 lpm flowmeters (white oxygen labeling)
2003FFEA NEO2 Blend with 15 lpm and 3.5 lpm flowmeters (white oxygen labeling) and bottom output
2007 Standard input fittings on blender are DISS air and oxygen. If you want NIST input fittings on your blender instead of DISS, add this part number to your order.
| Oxygen Concentraton Range | 21-100% |
|---|---|
| Number of ports | 2 or 3 (2 occupied by flow meters, bottom port present on 2003FFA model) |
| Left Flowmeter Range | 3-15 lpm (1-15 if bleed is on) |
| Right Flowmeter Range | 0-1.0, 0-3.5, 1-15 (with 3 lpm bleed on-flowmeter in upright position) |
| Accuracy | +/- 3% full scale |
| Bleed Flow | 3 lpm (when active) |
